Canopy, smoking cabin, material/bicycle shelter model Leipzig L14 - 430cm x 220cm - RAL 9002

✓ Robust steel construction – hot-dip galvanized & durable

✓ Versatile use as a bicycle shed or smoking shelter

✓ Modular kit system for easy self-assembly

✓ High stability up to 0.75 kN/m² snow load

✓ Free shipping directly to your home

SKU: 102000087-OHNE-OHNE-OHNE
additional side wall:

additional side wall
additional back panel:

additional back panel
rain gutter:

rain gutter
1.642,20 €

Tax included. Shipping calculated at checkout

Delivery time: 14 to 21 days

Quantity:

Canopy, Smoking Cabin, Material or Bicycle Shelter Model Leipzig L14 - RAL 9002

Kit with easy-to-understand assembly instructions for self-installation, made from a standardized flat roof basic system with trapezoidal sheet metal walls.
In combination with basic and extension units, and through the option of using trapezoidal sheet metal for back and side walls, a multitude of uses arises - open, semi-open, or closed. The practical corrugated sheet roofing has a three-sided, bolted fascia and drains rainwater to the rear. Rain gutters and downpipes are available upon request.

Dimensions:
Width: 4,300 mm
Depth: 2,200 mm
Height: 2,360 mm
Clearance Height: 2,175 mm

Technical Data:
Construction: Bolted / Kit
Roof Type: Flat roof / Trapezoidal sheet metal
Drainage: Free-draining at the rear, optional with rain gutter
Surface: Hot-dip galvanized or additionally color-coated - RAL 9002
Pipe Diameter: 60 mm
Rear / Side Wall: Support frame with trapezoidal sheet metal
Snow Load: 0.75 kN/m²
Weight: 210 kg
Wind Load Zone: Zone 1 to 2
Warranty: 5 years

Applications:

  • Bicycle shelter
  • Smoking cabin
  • Storage area canopy
  • Material canopy
  • Equipment canopy
  • Empty container storage
  • Waste area enclosure
  • Recyclables canopy
  • and much more.


Canopy, Smoking Cabin, Material / Bicycle Shelter Model Leipzig L14 - 430cm x 220cm - RAL 9002 - Kirchberger Metall Onlinevertrieb GmbH

Delivery:
Delivery is as a kit including foundation and assembly plan. Includes stainless steel floor fastening material (anchors).

Information on assembly and installation:
Assembly Instructions Leipzig - Click on the link!
