Canopy, smoking cabin, material/bicycle shelter model Leipzig L10 - 225cm x 220cm - RAL 9002

✓ Robust steel construction – hot-dip galvanized & durable

✓ Versatile use as a bicycle or smoking shelter

✓ Modular kit system for easy self-assembly

✓ High stability up to 0.75 kN/m² snow load

✓ Free shipping directly to your home

SKU: 102001866-OHNE-OHNE-OHNE
additional side wall:

additional side wall
additional back panel:

additional back panel
rain gutter:

rain gutter
1.656,48 €

Tax included. Shipping calculated at checkout

Delivery time: 14 to 21 days

Quantity:

Canopy, Smoking Cabin, Material or Bicycle Shelter Model Leipzig L10 - RAL 9002

Kit with easy-to-understand assembly instructions for self-assembly from a standardized flat roof basic system with walls made of trapezoidal sheet metal.
By combining basic and extension units, and through the possibility of using trapezoidal sheet metal for rear and side walls, a variety of uses is possible - open, semi-open or closed. The practical profiled sheet roofing has a three-sided, screwed fascia and drains rainwater to the rear. Gutters and downpipes are available on request.

Dimensions:
Width: 2,250 mm
Depth: 2,200 mm
Height: 2,360 mm
Clearance Height: 2,175 mm

Technical data:
Construction: Screwed / Kit
Roof type: Flat roof / Trapezoidal sheet metal
Drainage: Free dripping at the rear, optional with gutter
Surface: Hot-dip galvanized or additionally color-coated - RAL 9002
Pipe diameter: 60 mm
Rear / Side wall: Support frame with trapezoidal sheet metal
Snow load: 0.75 kN/m²
Weight: 176 kg
Wind load zone: Zone 1 to 2
Warranty: 5 years

Applications:

  • Bicycle shelter
  • Smoking cabin
  • Storage area canopy
  • Material canopy
  • Equipment shelter
  • Empty container storage
  • Waste enclosure
  • Recycling shelter
  • and much more.


Canopy, Smoking Cabin, Material / Bicycle Shelter Model Leipzig L10 - 225cm x 220cm - RAL 9002 - Kirchberger Metall Onlinevertrieb GmbH

Delivery:
Delivery is as a kit including foundation and assembly plan. Incl. stainless steel floor mounting material (dowels).


Information on assembly and installation:
Assembly instructions Leipzig - Click on the link!
