Smoking shelter, bicycle shelter, pedestrian shelter model Siegen S17 - 298cm x 233cm

✓ Robust steel construction – hot-dip galvanized & durable

✓ Modular system for easy expansion at any time

✓ Versatile use as a bicycle or smoking shelter

✓ High stability up to 0.85 kN/m² snow load

✓ Free shipping directly to your home

SKU: 102001584-OHNE-OHNE-OHNE
additional side wall:

additional side wall
additional back panel:

additional back panel
rain gutter:

rain gutter
1.523,20 €

Tax included. Shipping calculated at checkout

Delivery time: 21 to 28 days

Quantity:
5,0 82 Google-Bewertungen

Canopy, Smoking Cabin, Material or Bicycle Shelter Model Siegen S17 - Galvanized Steel

Modular design - whether small or large - easy to expand and quickly assembled. With "Siegen" you get a practical canopy in no time at all.
The basic system consists of a weatherproof mono-pitch roof with trapezoidal sheet metal covering and a galvanized round-tube steel construction. Side and rear wall elements are optionally available.
Thanks to the extension modules, you can easily enlarge your canopy at a later date. The kit is delivered for self-assembly. Easy-to-follow assembly and installation instructions are included. The profiled sheet metal canopy features a three-sided, bolted fascia that channels rainwater to the rear. Gutters and downpipes are available on request.

Applications:

  • Bicycle canopy
  • Smoking cabin
  • Storage area canopy
  • Material canopy
  • Equipment canopy
  • Empties storage
  • Waste bin enclosure
  • Recyclables canopy
  • and much more

Dimensions:
Width: 2.975 mm
Depth: 2.330 mm
Height: 2.250 mm
Clear height: 2.000 mm

Technical Data:
Construction: Bolted / kit
Roof type: Flat roof / trapezoidal sheet metal
Drainage: Free-draining at the rear, optionally with gutter
Surface: Hot-dip galvanized or additionally color-coated - RAL 9002
Tube diameter: 50 mm
Rear / side wall: Support frame with polyester infill, opal translucent, or as trapezoidal sheet metal variant
Snow load: 0,85 kN/m²
Weight: 212 kg
Wind load zone: Zone 1 to 2
Warranty: 5 years

Information on setup and installation:
Modellreihe-Siegen-Übersicht.pdfMontageanleitung Siegen.pdf

Raucherunterstand, Zweiradüberdachung, Personenunterstand Modell Siegen S17 - 298cm x 233cm - Kirchberger Metall Onlinevertrieb GmbHRaucherunterstand, Zweiradüberdachung, Personenunterstand Modell Siegen S17 - 298cm x 233cm - Kirchberger Metall Onlinevertrieb GmbHRaucherunterstand, Zweiradüberdachung, Personenunterstand Modell Siegen S17 - 298cm x 233cm - Kirchberger Metall Onlinevertrieb GmbH



Optional rear and side walls:

Optional side wall made of polyester

Optional side wall made of trapezoidal sheet metal

Optional rear wall made of trapezoidal sheet metal

Questions and Answers

A professional smoking shelter enables clean spatial separation in accordance with non-smoker protection laws without compromising the comfort of employees or guests. It also keeps the company premises clean, as it provides a central gathering point and minimizes uncontrolled littering.

The range extends from simple canopies open on one side to complex smoking pavilions or almost fully enclosed smoking cabins. The choice of the number of side walls directly affects the desired weather protection against wind, rain, or snow.

Yes, thanks to modular construction, the systems can be adapted flexibly. They can be optimally positioned on spacious open areas as well as in confined spaces such as courtyards or on roof terraces.

Functional components are available for the models (such as Modell K, Passau, or R). Combination ashtrays with an integrated waste bin are particularly space-saving and hygienic. To further increase comfort, we also offer weatherproof benches, standing tables, and integrated lighting systems.

From a technical standpoint, a level concrete foundation at the site is mandatory. The smoking shelter is professionally anchored to it using robust base plates to guarantee the necessary stability and structural safety under wind loads.

Yes, we assist you starting with the selection of the right size, taking maintenance and ease of cleaning into account. In addition to detailed documentation for efficient installation, we also offer a professional installation service for a code-compliant setup.

The optimal size depends on your desired site capacity and the required level of protection. In practice, around 0.5 to 1 square meter of space per person is usually calculated for a comfortable standing spot.

Systems such as Modell K, Passau, or R are based on modular constructions and are available in many sizes. The range extends from compact canopies open on one side for small teams to large, almost fully enclosed smoking pavilions or cabins. We are happy to help you select the right capacity for your premises.
