Smoking shelter, bicycle shelter, pedestrian shelter model Siegen S16 - 215cm x 233cm

Canopy, Smoking Shelter, Material or Bicycle Shelter Model Siegen S16 - Galvanized Steel

Modular design - whether small or large - easily expandable and quickly assembled. With "Siegen", you get a practical canopy in the shortest time.
The basic system consists of a weather-resistant lean-to roof with trapezoidal sheet metal roofing and a galvanized steel tubular construction. Side and back wall elements are optionally available.
Thanks to the expansion modules, you can easily enlarge your canopy even later. The kit is supplied for self-assembly. An easy-to-understand assembly and installation guide is included. The profiled sheet metal canopy has a three-sided, screwed-on fascia, which drains rainwater to the rear. Gutters and downpipes are available on request.

Applications:

• Bicycle shelter
• Smoking cabin
• Storage area canopy
• Material canopy
• Equipment shelter
• Empty container storage
• Waste area enclosure
• Recycling canopy
• and much more.

Dimensions:
Width: 2,145 mm
Depth: 2,330 mm
Height: 2,250 mm
Clearance height: 2,000 mm

Technical data:
Construction: Bolted / Kit
Roof type: Flat roof / Trapezoidal sheet metal
Drainage: Free-draining at the rear, optional with gutter
Surface: Hot-dip galvanized or additionally color-coated - RAL 9002
Tube diameter: 50 mm
Rear / Side wall: Support frame with polyester filling, opal transparent or as trapezoidal sheet metal version
Snow load: 0.85 kN/m²
Weight: 195 kg
Wind load zone: Zone 1 to 2
Warranty: 5 years

Information on assembly and installation:
Siegen Assembly Instructions - Click on the link!





Optional rear and side walls:

Optional side wall made of polyester

Optional side wall made of trapezoidal sheet metal

Optional rear wall made of trapezoidal sheet metal

Manufacturer:
Kirchberger Metall Onlinevertrieb GmbH
Neunburger Str. 2c
92431 Neunburg v. W. / Seebarn
Germany

Contact:
Email: shop@kirchberger-metall.de
Telephone: +49 (0) 9672 9269110
