Decorative fence Residenz select+ ZERMATT with posts - Color: Iron Mica DB703

Fence package - Decorative fence Residenz select+ with posts - Model ZERMATT with lace ornaments
Material: Galvanized and powder-coated steel in DB703 iron mica

The ZERMATT fence set consists of welded fence elements including matching posts and is offered in various heights up to a length of 30 m.
This decorative fence impresses above all with one thing: its simple yet elegant and contemporary design! The matte powder coating in a stylish grey metallic look makes the fence a real eye-catcher.

Available in galvanized and powder-coated (DB703 micaceous iron oxide) finishes. Special RAL colors are also available upon request.
Under normal weather conditions, the protective zinc layer lasts up to 30 years. The additional paint coating extends this protection for many more years.

Details:

• Lengths from 2m to 30m
• Fence package including the appropriate number of posts TYPE RS+
• Height: 900 mm or 1200 mm
• Grid length: 1910 mm
• Bar spacing: approx. 112 mm
• Bar thickness: 15 mm, cross bar = 25 x 25 mm
• Surface: galvanized and additionally high-quality powder-coated in color DB703 iron mica
• with lace ornaments

Delivery includes matching posts TYPE RS+:
including mounting hardware (mounting element and stainless steel screws)
Post profile: 60 x 60 mm
Post length:
1500 mm with a fence height of 900 mm,
1800 mm with a fence height of 1200 mm
Post color: same color as fence panel
Ground anchoring: for embedding in concrete

Precise length calculation and post spacing:
Axial post spacing: 1 fence panel = 2000mm -> 5 fence panels = 10,000mm
Clear post spacing: Fence panel length (1910 mm) plus 30 mm -> 1 fence panel = 1940 mm


Secure packaging and fast delivery:
Delivery by freight carrier, securely strapped to a disposable pallet.
Unpacking by the customer; no on-site assembly required.

Price includes shipping and delivery to the curb!

Questions and answers:

Can I cut or shorten the fence panels to fit?
Yes, you can cut the fence panels to size using an angle grinder. The cut edges should be coated with zinc spray and paint to protect against corrosion.
You can find the appropriate zinc and paint spray in the shop under >> Fasteners and Accessories <<

How can corners be designed?
For corners greater or less than 90°, simply use two posts. For a 90° corner, one post is sufficient.
Additional posts can be found here: >> RS+ fence posts <<

Are the posts only available for setting in concrete?
Yes, this standard product range only includes posts for setting in concrete.
However, the posts can also be shortened on the construction site, allowing the base plate adapter to be inserted into the post tube from below and the fence post to be bolted down.
The appropriate adapter is available here: >> Base plate 60x60 <<

How are the fence elements connected to the gatepost?
Gates are always supplied with two posts. The fence connection is made using the same standard mounting elements as the fence posts. Click here for the >> mounting element << .

Is there an assembly manual for an inexperienced fence installer?
Yes, the assembly instructions are automatically included with every shipment.
The assembly instructions can also be found here: >> Assembly instructions-Residenz-Select+.pdf <<
If you have any questions, you can also contact us by phone or email.
